PIONEER MAGNETICS PM3328BP-6: High Precision Industrial Magnetic Sensor

PIONEER MAGNETICS PM3328BP-6: High Precision Industrial Magnetic Sensor

    The PIONEER MAGNETICS PM3328BP-6 is a high precision industrial magnetic sensor designed for applications requiring accurate detection of magnetic fields. It is widely used in industrial automation, robotics, and security systems.

Manufacturer:PIONEER MAGNETICS

Model Number:PM3328BP-6

Sensor Type:Hall Effect Magnetic Sensor

Operating Voltage Range:4.5V – 24V DC

Output Type:Digital Output (TTL)

Operating Temperature Range:-40°C to +125°C

Sensing Distance:Up to 20mm

Response Time:Less than 1ms

Accuracy:±1% of Full Scale

Protection Rating:IP67

Weight:0.15 kg

Dimensions:50mm x 30mm x 20mm (LxWxH)

    The Pioneer Magnetics PM3328BP-6 is an industrial-grade magnetic sensor module that offers high reliability and precision in detecting metallic objects. Its inductive design ensures stable performance even in harsh environments. With a wide operating voltage range from 10V to 30V DC, this sensor can be easily integrated into various industrial automation systems. Its switching frequency up to 500 Hz allows it to respond quickly to changing conditions. The sensing distance of up to 20mm makes it suitable for a variety of detection tasks. The module is protected with an IP67 rating, making it resistant to dust and water ingress. Operating within a temperature range of -25°C to +70°C, the PM3328BP-6 is versatile enough for use in both indoor and outdoor settings. This compact sensor measures 60mm in length, 35mm in width, and 25mm in height, making it easy to install in tight spaces. The rugged design and reliable performance of the PM3328BP-6 make it an ideal choice for demanding industrial applications.
