GE 760-P5-G5-S5-HI-A20-R-T: Advanced Feeder Management Relay with Enhanced Display and Ethernet Connectivity
The GE 760-P5-G5-S5-HI-A20-R Multilin Relay is an advanced industrial protection relay featuring an enhanced display and Ethernet connectivity, enabling seamless integration into modern industrial networks. Equipped with eight 4-20mA analog outputs, this relay offers robust monitoring and control capabilities essential for efficient power distribution systems.
Model:760-P5-G5-S5-HI-A20-R-T
Ambient Storage Temperature Range:-40°F to +176°F
Operating Temperature Range:-40°F to +140°F
Pollution Degree:II
Dimensions:Approximately 18cm W x 16.5cm L x 21.5cm H
Relay Dimensions:approx. 18cm W, 16.5cm L, 21.5cm H
Communication Ports:Ethernet, RS232, RS422, RS485
Analog Input Conversion Range:0 to 21 mA
Baud Rate:300 to 19200 baud
Overvoltage Pickup Level:0 to 1.25 × VT in steps of 0.01
Waveform Capture Channels:4 currents, 3 voltages, 14 logic input states and 8 output relays
The GE 760-P5-G5-S5-HI-A20-R Multilin Relay is an advanced device tailored for the needs of industrial automation and power system protection. With its robust design and high precision, this relay is capable of monitoring, managing, and protecting distribution feeder systems with unmatched accuracy. Its enhanced faceplate provides a clear and intuitive interface, making configuration and operation simple and efficient.
Equipped with Ethernet connectivity and eight 4-20mA analog outputs, the GE 760-P5-G5-S5-HI-A20-R Multilin Relay supports seamless integration with modern industrial networks. The advanced waveform capture channels allow for real-time monitoring of up to four currents, three voltages, and 14 logic input states, ensuring reliable protection against faults.
Designed with the end-user in mind, this relay features a compact and durable housing that can withstand harsh environmental conditions. With pollution degree rating II, it ensures stable performance even under severe conditions.
Moreover, the inclusion of closed red breaker LEDs offers instant visual feedback on the status of breakers, enhancing safety and operational efficiency.
This relay is a must-have for any industrial control application requiring robust and reliable protection.
