Rockwell Automation 9101-1677-010DRV-RT ANGLE N3400,4200,5600 MTR ENCODER

Rockwell Automation 9101-1677-010DRV-RT ANGLE N3400,4200,5600 MTR ENCODER

    The Rockwell Automation A-B 9101-1677-010Drv-Rt Angle Encoder is a high-precision device designed for accurate measurement and control of motor shaft angles in N3400, 4200, and 5600 series motors. It finds applications in industrial automation, robotics, and manufacturing systems where precise motion control is essential.

Manufacturer:Rockwell Automation

Model Number:9101-1677-010

Drive Type:Drv-Rt Angle

Motor Compatibility:N3400, 4200, 5600 Series Motors

Measurement Range:0 to 360 degrees

Accuracy:+/- 0.1 degree

Operating Voltage:10-30VDC

Output Signal:Incremental Pulse

Environmental Rating:IP67

Operating Temperature:-40°C to +85°C

    The Rockwell Automation 9101-1677-010DRV-RT ANGLE N3400,4200,5600 MTR ENCODER is engineered for high-precision applications in industrial automation and robotics. This encoder offers robust performance with support for multiple motor types including N3400, 4200, and 5600 models. Its absolute encoding technology ensures accurate angular position measurement, even after power interruptions. With resolutions up to 17-bit, it delivers exceptional precision in positioning tasks. The encoder is designed to operate within a wide voltage range of 10-30VDC, making it adaptable to various industrial setups. It supports SSI, BISS, and EnDat signal outputs for seamless integration with existing systems. Constructed with durability in mind, this encoder boasts an IP67 protection rating, ensuring it can withstand harsh industrial conditions. Installation is straightforward, with clear markings and easy-to-follow instructions included in the package. Ideal for use in manufacturing, assembly lines, and robotic systems where precision and reliability are paramount.
