NI SCXI-1193 Industrial Control Module

NI SCXI-1193 Industrial Control Module

    The NI SCXI-1193 is a high-performance industrial control module designed to deliver reliable and precise control for a wide range of automation applications. Built for durability and efficiency, this module ensures seamless operation in demanding environments.

Brand:NI

Model:SCXI-1193

Module Type:Data Acquisition

Input Channels:8 differential or 16 single-ended

Resolution:16-bit

Sampling Rate:Up to 250 kS/s

Analog Input Range:+/-10 V

Input Impedance:1 MΩ

Power Supply:24 V DC

Operating Temperature:-40°C to +85°C

Certifications:CE, RoHS

    The NI SCXI-1193 Signal Conditioning Module offers unparalleled precision and reliability for signal conditioning in demanding industrial environments. Designed by National Instruments, this module is built to withstand harsh conditions while providing accurate amplification and filtering capabilities.

    This signal conditioning module features four input channels capable of handling voltage ranges from ±10V, making it ideal for a wide range of applications including manufacturing processes, environmental monitoring, and scientific research. Its gain range of 1 to 100 allows for flexible adjustment to meet specific requirements.

    The module supports a bandwidth from DC to 10 kHz, ensuring that it can capture fast-changing signals without distortion. With an isolation voltage of 250 VRMS, it ensures safe operation in electrically noisy environments, minimizing interference and ensuring reliable data acquisition.

    Common mode rejection ratio (CMRR) of ≥80 dB guarantees minimal interference from common mode noise, enhancing the overall signal integrity. The module operates within a broad temperature range of -40°C to +85°C, making it suitable for use in extreme environments.

    Designed for ease of use, the NI SCXI-1193 is equipped with an RJ45 connector for convenient connection to compatible systems. Its compact dimensions of 4.5 x 2.5 x 0.7 inches make it easy to integrate into existing setups without requiring extensive modifications.
