NI PXIE-4499 High-Speed Data Acquisition Module

NI PXIE-4499 High-Speed Data Acquisition Module

    The NI PXIE-4499 is a high-performance data acquisition module designed for industrial control systems. It offers advanced data capture capabilities with exceptional accuracy and reliability, suitable for applications requiring precise measurements.

Manufacturer:National Instruments

Model Number:PXIE-4499

Series:High-Speed Data Acquisition Modules

Bus Interface:PCIe x8 Gen 2

Sampling Rate:Up to 25 MS/s per channel

Analog Input Channels:8 channels

Resolution:16-bit

Input Range:+/-10 V

Clock Source:Internal or External

Trigger Modes:Software, Hardware, External

Operating Temperature:-40°C to +85°C

    Designed for seamless integration into existing industrial control systems, the NI PXIE-4499 offers a robust solution for high-speed data acquisition. It features eight analog input channels with a resolution of up to 16 bits, allowing for precise measurement and recording of industrial processes.

    The module supports sampling rates of up to 25 million samples per second per channel, making it ideal for capturing fast-changing signals in real-time. This ensures accurate and timely data collection, which is crucial for maintaining operational efficiency.

    With a wide input range of +/-10V, the NI PXIE-4499 can handle a variety of signal levels without the need for external amplifiers, reducing complexity and cost. Its versatile trigger modes allow for flexible synchronization with other instruments and systems.

    Built to withstand harsh industrial environments, the PXIE-4499 operates within a temperature range of -40°C to +85°C, ensuring reliability in extreme conditions. Its PCIe x8 Gen 2 bus interface provides high-speed data transfer capabilities, enhancing system performance.

    For added convenience, the module supports both internal and external clock sources, giving users the flexibility to choose the most suitable timing source for their application. The NI PXIE-4499 is a vital component for any industrial control setup requiring precise and rapid data acquisition.
