NI PXI-6514 Data Acquisition Card for High Precision Measurement
The NI PXI-6514 is a high-precision data acquisition card designed for industrial automation systems. It excels in providing reliable signal measurement and conversion capabilities, making it ideal for use in test and measurement applications.
Interface Type:PXI Express
Channels:48 Differential or 96 Single-Ended
Sampling Rate:Up to 1 MS/s per channel
Resolution:16 bits
Input Range:+/-10V, +/-5V, +/-2.5V, +/-1.25V, +/-0.625V
Analog Input Types:Differential and Single-Ended
Digital I/O:32 lines
Compatibility:Compatible with NI-Sync technology
Dimensions:3U PXI form factor
Weight:Approximately 0.5 kg
The NI PXI-6514 is an essential tool for any engineer working in digital signal processing and data acquisition. With its robust design, it can handle up to 64 channels, making it ideal for applications requiring high-density connectivity.
Equipped with dual-port SubD connectors, this module supports flexible wiring configurations, reducing setup time and enhancing system scalability. Its compatibility with 5V TTL/CMOS voltage ensures seamless integration with a wide array of digital devices.
Designed for reliability, the PXI-6514 maintains precise digital I/O performance even under challenging environmental conditions, with an operating temperature range from -40°C to +85°C.
The module’s compact form factor makes it suitable for use in space-constrained environments, such as automated test systems and industrial control panels. It is powered by standard PXI bus power, consuming only 2W of power, which minimizes energy costs and thermal load.
Easy to install and configure, the PXI-6514 integrates smoothly into existing PXI systems. Its intuitive operation and reliable performance make it a valuable addition to any digital signal processing application.
