National Instruments cFP-SG-140 Signal Generator Module
The National Instruments cFP-SG-140 is an advanced analog signal generator module designed for industrial control systems. It enables precise control over analog signals in various applications, providing reliable performance in a rugged environment.
Manufacturer:National Instruments
Model Number:cFP-SG-140
Signal Generation Range:DC to 50 MHz
Amplitude Range:+/- 10V
Waveform Types:Sine, Square, Triangle, Arbitrary
Connector Type:BNC Connectors
Power Supply Requirements:±15V DC, 500 mA max
The National Instruments cFP-SG-140 Signal Generator Module is an integral part of Compact FieldPoint systems, enabling precise control over waveform generation. Its design includes robust connectivity options, allowing seamless integration with existing setups.
This module supports a variety of waveform types including sine, square, triangle, ramp, and arbitrary waveforms. This versatility makes it ideal for a broad spectrum of applications from basic testing to advanced research.
With a frequency range spanning from 0.1 Hz to 1 MHz and a resolution of 16 bits, the cFP-SG-140 ensures accurate signal generation under a wide array of conditions. The high sampling rate of up to 2 MS/s guarantees smooth and continuous waveform output.
Designed with the IEEE 1451.2 Smart Transducer Interface standard, the cFP-SG-140 facilitates easy communication between transducers and the module, streamlining setup and maintenance processes.
Installation is straightforward, thanks to its plug-and-play compatibility with Compact FieldPoint systems. Users benefit from reduced setup time and enhanced reliability, ensuring that the module performs optimally right out of the box.
