Microchip PIC16F684ISL 8-Bit Microcontroller – Industrial Automation
The Microchip PIC16F684ISL is a versatile 8-bit microcontroller designed for a wide range of applications including consumer electronics, industrial automation, and automotive systems. It features a 14-pin DIP package for easy integration into existing systems and offers robust performance with low power consumption.
Microcontroller Core:PIC16F684
Operating Voltage Range:2.0V to 5.5V
Flash Memory:1K x 14 Program Memory
RAM:64 Bytes Data Memory
EEPROM:64 x 8 Nonvolatile Data Memory
Clock Frequency:20 MHz
I/O Ports:13 Digital I/O Pins
Package Type:18-pin PDIP, SOIC
Temperature Range:-40°C to +85°C
Designed with advanced architecture, the PIC16F684ISL microcontroller delivers exceptional performance in a compact package, making it ideal for space-constrained applications. It supports a wide voltage range, enabling seamless integration into various power supply environments.
Equipped with multiple communication interfaces such as UART, SPI, and I²C, the PIC16F684ISL facilitates easy connectivity with other system components, enhancing system flexibility and scalability.
This microcontroller includes robust security features like code protection, data EEPROM, and lock bits, ensuring the integrity of your application code and data.
The built-in analog comparators and PWM channels provide versatile functionality for analog signal processing and motor control applications.
With its efficient operation and reliable performance, the PIC16F684ISL microcontroller is an excellent choice for developers looking to build reliable and high-performance embedded systems.
