General Electric DS3800NHVJ1A1A High Voltage Board Component
The DS3800NHVJ1A1A is a critical component for steam and gas turbine management, enhancing efficiency and reliability. This high-voltage board is designed for monitoring fuel and air emissions and automating startup and shutdown processes, ensuring smooth operations in power generation facilities.
Board Type:High Voltage Board
Series:Mark IV
Compatibility:For Steam and Gas Turbine Management Systems
Pin Connectors:Two vertical pin (male) communication connectors
LEDs:Six light emitting diodes (LEDs)
Contact Points:Six contact points
Jumpers:Five jumper switches that can sit at H or B
Resistors:Carbon composite and ceramic-covered metal film resistors
Capacitors:Various value capacitors
Drilled Holes:Factory drilled holes for alignment and mounting
The DS3800NHVJ1A1A is a critical component for managing steam and gas turbines. Designed by General Electric, it ensures reliable operation with its advanced monitoring capabilities for fuel and air emissions. Key features include automation of start-up and shutdown processes, minimizing downtime with integrated chipset redundancy.
This high voltage board is meticulously engineered to meet the stringent demands of industrial applications. Its robust design includes factory-drilled holes for precise alignment and markings for accurate placement. The board supports multiple connection options, including two vertical pin (male) communication connectors, six LEDs, and six contact points. Additionally, it features five jumpers that can be set to H or B, enhancing flexibility and customization.
Installation is straightforward, thanks to comprehensive guidelines provided by General Electric. The board’s detailed labels and clear instructions ensure safe and efficient integration into existing systems, making it a reliable choice for maintenance and upgrade projects.
Choose the DS3800NHVJ1A1A for unparalleled reliability and performance in your turbine management systems.
