General Electric DS3800HPTN1J1H – High-Power Turbine Control Module

General Electric DS3800HPTN1J1H – High-Power Turbine Control Module

    This GE DS3800HPTN1J1H Gate Driver Board is a high-performance component designed specifically for the Mark IV Speedtronic turbine control systems. It ensures precise control and efficient operation of the turbine system, making it a critical part for industrial applications.

Manufacturer:General Electric

Model:DS3800HPTN1J1H

Board Type:Gate Driver

Compatibility:Mark IV Speedtronic Turbine

Connector Prongs:10

Resistor Rating:18 Ohms ±5%

Power Rating:10 Watts

Dimensions:Varies by Application

Weight:Varies by Application

Certifications:CE, ISO 9001

    The DS3800HPTN1J1H is meticulously crafted for use in the most demanding industrial environments. Its robust design includes two transistors housed within a thick black metal fence, providing exceptional durability and reliability under extreme conditions. The board is equipped with over twenty resistors, including ten with colored lines indicating their energy capabilities, ensuring precise and consistent performance. Additionally, fifteen elongated grey rectangle resistors are valued for their stability at eighteen Ohms with a variance of plus or minus five percent and a ten-watt rating, contributing to its high power handling capability. The board’s compact form factor allows for easy installation in tight spaces without compromising on performance. Key components are labeled with alphanumeric identifiers for quick and accurate maintenance and troubleshooting. With its cutting-edge design and high-quality materials, the DS3800HPTN1J1H is a cornerstone in any modern turbine control system.
