General Electric DS3800HPTK Gate Driver Board for Mark IV Speedtronic Series
The DS3800HPTK Gate Driver Board is an essential component designed by General Electric for the Mark IV Speedtronic series. It facilitates the operation of high-power transistors, enhancing system efficiency and reliability.
Manufacturer:General Electric
Model Number:DS3800HPTK
Series:Mark IV Speedtronic
Resistor Capacity:15 x 18Ω ±5% (10W)
Color-coded Resistors:10 resistors with color bands indicating their current capacity
Diodes:13 variously colored diodes
Capacitors:3 capacitors ranging from small to large
Glass Fuse:Large glass fuse included
LED Indicator:Small red LED for status indication
Potentiometer:Small blue potentiometer for fine-tuning resistance
The General Electric DS3800HPTK Gate Driver Card is meticulously crafted to meet the rigorous demands of industrial control applications. It serves as a vital component within the Mark IV Speedtronic system, ensuring reliable operation and precision control.
This card features fifteen long grey resistors rated for eighteen Ohms with a tolerance of plus or minus five percent, and they are all rated for ten watts. Ten additional resistors are color-coded to indicate their current capacity. Additionally, there are thirteen diodes of various colors which enhance the card’s functionality.
Three capacitors of different sizes are included to provide stable power delivery. The card also contains a large glass fuse and a small red LED for status indication. A small blue potentiometer or variable resistor allows for fine-tuning of settings, making this component versatile and adaptable to a range of applications.
