General Electric DS200IQXSG1AAA Inverter Snubber Board for Mark V Turbine Control System
The DS200IQXSG1AAA is a specialized printed circuit board designed by General Electric for use in the Mark V Turbine Control System. It serves as an Inverter Snubber Board, ensuring efficient power distribution and line protection.
Manufacturer:General Electric
Series:Mark V
Part Number:DS200IQXSG1AAA
Functional Description:PC Board Line Protection Card
Functional Acronym:IQXS
PCB Coating:Normal Coating
Functional Revision:1A
Artwork Revision:A
Designed for the Mark V Turbine Control System, the DS200IQXSG1AAA Inverter Snubber Board ensures stable operation and enhanced reliability under demanding industrial conditions.
This board incorporates a series of standardized hardware components, including capacitors, resistors, transistors, diodes, and integrated circuits, which contribute to its robust design and efficient performance.
With built-in protection features such as overvoltage, overcurrent, and short circuit protection, the DS200IQXSG1AAA board provides a secure and dependable solution for industrial environments.
The board’s ability to function within a wide range of temperatures (-40°C to +85°C) and humidity levels (up to 95% non-condensing) makes it suitable for use in various industrial settings, from manufacturing plants to power generation facilities.
Installation and maintenance of the DS200IQXSG1AAA Inverter Snubber Board are straightforward, thanks to its user-friendly design and comprehensive documentation. This board is a reliable choice for enhancing the performance of Mark V turbine control systems.
