GE SR745-W2-P5-G5-HI – Advanced Transformer Protection System for Industrial Applications
Engineered for transformer systems management and safeguarding, the GE Multilin SR745-W2-P5-G5-HI Transformer Protection System enhances transformer performance and longevity, featuring real-time response capabilities and comprehensive monitoring.
Model Number:745-W2-P5-G5-HI
Brand:GE / General Electric
Protection Type:Transformer, Autotransformer, Reactor
Windings Per Phase:2
Resistant Temperature Device (RTD) Type:3-wire; 100 Ω Nickel, 120 Ω Nickel, 100 Ω Platinum
Analog Output Maximum Load:10 kΩ at 0 to 1 mA, 600 Ω at 4 to 20 mA
Maximum Continuous Voltage Output:273 V
Display Type:40-character Enhanced LCD
Dimensions:9”H x 7 ⅛”D x 7”W
Control Power Range:90 to 300 V DC; 70 to 265 V AC at 48 to 62 Hz
The GE SR745-W2-P5-G5-HI is a cutting-edge transformer protection system designed to manage and safeguard critical electrical assets like transformers, autotransformers, and reactors. With its advanced 40-character display and expanded keypad, it allows for easy manual entry of setpoints. The system can be mounted on a standard 19-inch panel, providing a compact yet robust solution for industrial applications. Key design highlights include a durable SR 745 series chassis that ensures reliability and durability in demanding environments. Its technical specifications include two windings per phase and a resistant temperature device (RTD) available in 100 Ω Nickel, 120 Ω Nickel, or 100 Ω Platinum configurations. The analog output maximum load supports up to 10 kΩ at 0 to 1 mA and 600 Ω at 4 to 20 mA, ensuring accurate and reliable measurements. The system’s maximum continuous voltage output is 273 V, and the control power range extends from 90 to 300 V DC or 70 to 265 V AC at 48 to 62 Hz, making it highly adaptable to various operating conditions.
