GE Multilin 269PLUS-120N-120 Motor Management Relay, Motor Protection
The General Electric 269PLUS-120N-120 is an advanced motor management relay designed for efficient protection and monitoring of medium-sized AC motors. It features a robust design and high accuracy, making it ideal for industrial environments where reliability and performance are paramount.
Manufacturer:General Electric Multilin
Location:Markham, Ontario, Canada
Model Number:269PLUS-120N-120
Software:EnerVista 269
Shipping Dimensions:11.40″ x 7.50″ x 16.00″ (W × H × D)
Shipping Weight:7.75 lb
Switch Inputs:Type Dry Contacts
Temperature Range:-25°C to +60°C ambient
IP Rating:40X
Nickel RTD Resistance:120 Ohm
Phase Reversal Response Time:within 3.5 sec. of motor start attempt
Control Power AC Nominal:120 VAC, range: 90-150 VAC
Overload Curve Detection:±1% of primary CT amps
Phase Current Input Range:0.05 to 12 × phase CT primary amps setpoint
The GE Multilin 269PLUS-120N-120 Motor Management Relay is an advanced solution for ensuring reliable motor operations in industrial environments.
Its nickel RTD monitors temperature within the motor system, providing precise measurements for optimal motor health.
Designed with a drawout construction, it allows for easy replacement, calibration, or testing without interrupting the motor’s operation.
With its robust design and advanced features, this relay is a cornerstone in motor protection and monitoring.
The relay supports multiple protection mechanisms including speed device protection, undercurrent/minimum load protection, and overtemperature protection.
Ideal for industrial applications requiring high precision and reliability, this relay delivers exceptional performance and durability.
