GE DS3800NHVE1B1A High Voltage Board for Gas or Steam Turbine Control
The DS3800NHVE1B1A is a critical component of GE’s Mark IV turbine control systems. Designed for high voltage operations, this printed circuit board facilitates efficient management of gas or steam turbines by automating basic procedures and monitoring essential parameters.
Model:DS3800NHVE1B1A
Manufacturer:General Electric
Category:Mark IV Line
Functionality:High Voltage Board
Alignment Markings:Letters and Numbers on Two Edges
Board Drilling:Factory-drilled dead-center and in all corners
Connectors:Two Vertical Pin (Male) Communication Connectors
LEDs:Six Light Emitting Diodes
Contact Points:Six Contact Points
Jumpers:Five Jumpers, Settable to H or B
Resistors:Carbon Composite and Ceramic-Covered Metal Film
Capacitors:Various Capacitor Values
This high voltage board, designed specifically for the Mark IV line from General Electric, plays a vital role in the efficient operation of gas or steam turbines.
With the capability to automate crucial procedures such as startup and shutdown, it ensures smooth and reliable operation.
The DS3800NHVE1B1A board comes equipped with alignment markings on two edges, enabling easy installation and accurate positioning.
It features six LED indicators that offer visual confirmation of operational status.
Five adjustable jumpers allow users to fine-tune settings, ensuring optimal performance under varying conditions.
The use of high-quality resistors and capacitors contributes to the board’s reliability and durability.
