GE 531X171TMAABG1 Terminal Board Relay Card, 531X Series
The GE 531X171TMAABG1 is a terminal board relay card designed for use in industrial control systems. It plays a crucial role in the efficient operation and management of electrical circuits within these systems. This card integrates advanced components like electrolytic capacitors and resistors, making it an essential component for modern control applications.
Manufacturer:General Electric
Model Number:531X171TMAABG1
Board Type:Terminal Board Relay Card
Series:531X Series
Compatibility:For GE Boards & Turbine Control Systems
Dimensions:Refer to the user guide for specific dimensions
Weight:Refer to the user guide for specific weight
Voltage Rating:Refer to the user guide for specific voltage rating
The General Electric 531X171TMAABG1 is a high-quality terminal board relay card meticulously designed for industrial control systems.
Featuring robust electrolytic capacitors and resistor network arrays, this board ensures reliable performance under demanding conditions.
With seven potentiometers and a single switch component marked ‘Tach range,’ it provides fine-tuned control over a wide range of applications.
Six resistor network arrays further enhance its capability to manage complex electrical circuits efficiently.
The board includes two vertical pin (male) cable connectors and a single 16-pin header connector, making installation straightforward.
Additionally, a 3-screw terminal strip located at one corner of the board allows for secure connections, marked on one side as TACH (-) and on the other as TACH (+), facilitating accurate speed measurements.
