Allen-Bradley B809157-A-DRAGPCB, Stepper Interface PCB Assembly
The Rockwell Automation B809157-A-DRAGPCBASM is a high-performance stepper interface module designed for industrial control systems. It enables precise motion control in various applications, ensuring smooth operation and efficient performance.
Manufacturer:A-B
Model:B809157-A-DRAG
Module Category:Stepper Interface (DRAG)
Dimensions:2.1 cm x 18.8 cm x 26.2 cm
Weight:0.36 kg
Operating Voltage:12V – 24V DC
Current Rating:Up to 5A
Communication Protocol:RS-485
Input Signals:Pulse and Direction
Output Signals:Stepper Motor Drive Signals
The Rockwell A-B B809157-A-DRAG is an advanced stepper interface PCB assembly designed for demanding industrial automation applications.
This module is built with high-quality materials and precision components to deliver unparalleled accuracy and reliability.
Its robust design allows it to operate under extreme environmental conditions, making it suitable for use in manufacturing plants, robotics, and other industrial settings.
The assembly includes a digital interface capable of handling up to 4-phase stepper motors, ensuring smooth and precise motion control.
With a wide input voltage range from 10V to 30V DC, this interface board can be easily integrated into existing systems.
The compact size and lightweight design make installation straightforward, while its rugged construction ensures longevity even in harsh operating environments.
