Allen-Bradley 845H-NXC7946-FW1 Size 25 Frame Incremental Encoder, Reliable Feedback for Industrial Automation

Allen-Bradley 845H-NXC7946-FW1 Size 25 Frame Incremental Encoder, Reliable Feedback for Industrial Automation

    This Allen-Bradley encoder provides precise feedback for industrial applications, featuring a robust design suitable for harsh environments. Ideal for use in manufacturing, robotics, and other automated machinery.

Manufacturer:Rockwell Automation

Model:845H-NXC7946-FW1

Frame Size:Size 25

Type:Incremental Encoder

Output Signal:Push-pull, TTL

Resolution:5000 pulses per revolution

Supply Voltage:10-30V DC

Shaft Diameter:10mm

Shaft Length:20mm

Shaft Material:Steel

Operating Temperature:-20°C to +85°C

Storage Temperature:-30°C to +90°C

Weight:Approx. 0.5kg

    The Allen-Bradley 845H-NXC7946-FW1 Size 25 Frame Incremental Encoder is designed for demanding industrial environments where precision and durability are critical. This encoder boasts a robust stainless steel shaft sealed against environmental contaminants, ensuring longevity even under harsh conditions. Its high pulse resolution of 1024 P/R allows for precise positioning control, making it an excellent choice for robotics and manufacturing automation. With an operating voltage range of 10 to 30 V DC, this encoder is versatile enough to fit a wide range of applications. The push-pull, differential output type enhances signal integrity over long cable runs, ideal for industrial setups requiring reliable communication. The IP65 rating guarantees protection against dust and water jets, making it suitable for outdoor and indoor use alike. The Allen-Bradley encoder is built to last, boasting a mechanical life of up to 50 million operations, thus reducing maintenance costs and downtime. By choosing the Allen-Bradley 845H-NXC7946-FW1, you invest in a solution that combines reliability with advanced engineering to meet the needs of today’s industrial automation landscape.
