Allen-Bradley 1746-NIO4V High-Resolution Analog Combination Module

Allen-Bradley 1746-NIO4V High-Resolution Analog Combination Module

    The Allen Bradley 1746-NIO4V/A SLC500 Analog Combination Module is a high-resolution analog input/output module designed for industrial control systems. It combines 2 channels of analog input and 2 channels of analog output, making it ideal for applications requiring precise measurement and control.

Model Type:SLC500

Model Number:1746-NIO4V/A

Manufacturer:Allen Bradley

Module Type:Analog Combination Module

Resolution:High Resolution

Input Channels:2

Output Channels:2

Input Voltage Range:-20 to 20 V

Absolute Input Voltage:+/- 7.5 VDC or 7.5 VAC RMS (Maximum)

Input Current Range:-20 to 20 mA

Absolute Input Current:-30 to 30 mA (Maximum)

Output Range:-10 to 10 V – 1 LSB

Full Scale Output:10 VDC

Overvoltage Protection:7.5 VAC RMS

Output Voltage Range:-10 to 10 VDC – 1 LSB

Backplane Current Draw:55 mA

    The Allen-Bradley 1746-NIO4V/A is an essential component for any industrial automation system requiring precise analog signal processing.

     This module provides two channels each for input and output, enabling versatile connectivity options.

     With a high resolution and wide voltage and current range, this module ensures accurate and reliable data acquisition and control.

     Its robust design and overvoltage protection make it suitable for demanding industrial environments.

     The compact form factor allows easy integration into existing systems without compromising performance.

     Whether you’re monitoring temperature, pressure, or other critical parameters, the 1746-NIO4V/A delivers the precision and reliability needed for efficient operation.
