ABB S-093H

• Electrical Parameters:
  • Input Voltage: 24 V DC (phase module); 12 kV (circuit breaker).
  • Output Voltage: Up to 24 V DC (phase module); rated current 630 A (circuit breaker).
  • Operating Temperature Range: -20°C to +60°C (phase module); -40°C to +100°C (some industrial variants).
  • Protection Class: IP20 (phase module); IP54 (circuit breaker).
• Communication & Interfaces:
  • Supports Ethernet/IP, Modbus TCP/IP, RS232, and PROFINET (phase module).
  • Compact design for easy integration into control cabinets.

2. Key Features

• Phase Module (3BHB030478R0309):
  • High-precision phase measurement and control using advanced algorithms.
  • Real-time monitoring of three-phase power supply sequence to prevent equipment damage from incorrect phasing.
  • Built-in phase balance detection to ensure stable operation of connected devices.
• High-Voltage Circuit Breaker (3BHB009885R0004):
  • High reliability with a breaking capacity of 31.5 kA.
  • Integrated overload, short-circuit, and ground fault protection.
  • Robust construction with metal and plastic components for durability.
• Solid-State Relay (SSR):
  • Zero-voltage switching technology reduces electromagnetic interference (EMI).
  • Suitable for resistive or inductive loads (e.g., heaters, motors).
  • Long service life with no mechanical wear.

3. Functional Applications

• Phase Module:
  • Motor Control Systems: Ensures correct phase sequence for safe motor startup.
  • Power Electronics: Used in high-voltage frequency converters for precise speed and torque control.
  • Industrial Automation: Integrates with DCS and PLC systems for process optimization.
• High-Voltage Circuit Breaker:
  • Mining & Heavy Industry: Protects grinding mill drives and other critical equipment from electrical faults.
  • Energy Distribution: Safeguards transformers and switchgear in substations.
• Solid-State Relay:
  • Temperature Control: Regulates heating elements in plastic extruders and industrial ovens.
  • Lighting Systems: Enables smooth dimming and switching in high-power applications.

4. Industry Applications

• Phase Module:
  • Widely deployed in HVAC systems, water treatment plants, and renewable energy installations (e.g., wind turbines, solar inverters).
• High-Voltage Circuit Breaker:
  • Essential for mining operations, cement plants, and metallurgical processes where equipment reliability is critical.
• Solid-State Relay:
  • Used in automotive manufacturing, food processing, and chemical production for precise load control.

5. Advantages

• High Precision: Phase modules offer millisecond-level response for dynamic systems.
• Safety: Circuit breakers comply with international standards (e.g., IEC 62271) for fault protection.
• Energy Efficiency: SSRs reduce power waste by eliminating contact resistance.
• Scalability: Modular design allows customization for specific industrial needs.

6. Typical System Configurations

• Phase Module Integration:
  • Paired with ABB AC800M controllers or UFC921A CPU modules for centralized automation.
  • Connected via PROFINET or Ethernet to HMI panels for real-time monitoring.
• Circuit Breaker Setup:
  • Installed in ring motor drives (GMDs) for mining mills, ensuring uninterrupted operation under heavy loads.
• SSR Deployment:
  • Combined with temperature sensors (e.g., AI830A) in closed-loop control systems for precise thermal management.
