ABB 3BHB030310R0001

• Short-Circuit Breaking Capacity: Capable of handling short-circuit currents up to 25kA.
• Operating Temperature Range: Designed to function reliably in temperatures ranging from -25°C to 70°C.
• Protection Rating: IP20, ensuring protection against solid objects larger than 12.5mm and water sprays.
• Dimensions: 24.5×14.5×3.2 cm or 20cm x 15cm x 10cm, depending on the configuration.
• Weight: Approximately 1kg to 3.7kg, depending on the specific model and configuration.
• Frequency: 50Hz.
• Rated Voltage: 230/400V.
• Rated Power: 45kW.

Functional Features

• High Efficiency: Optimized for efficient operation, ensuring reliable system performance.
• High Precision Control: Suitable for applications requiring precise control over industrial processes.
• Modular Design: Easy to install and maintain, with a flexible design that allows for easy upgrades and replacements.
• Reliability: Manufactured with high-quality materials, ensuring durability and performance in harsh environments.
• Cooling Method: Equipped with a fan-cooling system to maintain optimal operating temperatures.

Application Scenarios

The ABB 3BHB030310R0001 is widely used in various industrial applications, including:

• Industrial Automation: For signal processing and safety monitoring in automated systems.
• Power Systems: Suitable for high-voltage and high-current power electronic applications.
• Mechanical Manufacturing: Commonly used in industries such as wind power generation and water pump control.
• Transportation: Used in rail transit systems for efficient control and monitoring.
• Metallurgy and Petrochemical Industries: Provides efficient and stable power management solutions.

Supported Industrial Protocols

The module supports a range of industrial protocols, including:

• ProfiBus-DP: Compliant with IEC61158 TYPE3 and Chinese National Standard GB/T 20540-2006, with adaptive baud rates from 9600 to 12Mbps.
• CANopen: Conforms to CAN2.0A and CANopen CiA Draft Standard 301, with configurable baud rates for flexible communication.
• ABB Proprietary Protocols: Ensures seamless integration with ABB control systems.

Scalability

The ABB 3BHB030310R0001 is designed with scalability in mind, allowing for easy expansion and integration into existing systems. Its modular design and support for multiple communication protocols make it adaptable to various industrial environments. The module can be easily configured and expanded to meet the evolving needs of industrial automation and control systems.
