A-B 571867-RPF6000 PWM Board, High Performance Industrial Control Module
The A-B 571867-RPF6000 PWM Board is an advanced pulse width modulation module designed for industrial control applications. It ensures precise control over electric drives and motors by generating high-frequency pulses, making it ideal for manufacturing environments where accuracy and reliability are paramount.
Manufacturer:Allen-Bradley
Model Number:571867-RPF6000
Firmware Version:FW6.002 SP
Type:PWM Board
Input Voltage Range:20-24VDC
Output Current:Up to 10A
Frequency Range:0-20kHz
Control Method:Pulse Width Modulation
Operating Temperature:-40°C to +85°C
Storage Temperature:-55°C to +125°C
Dimensions:150mm x 100mm x 30mm
Weight:1.5kg
The Allen Bradley A-B 571867-RPF6000 PWM Board comes with firmware version FW6.
002 SP, which enhances its performance in various industrial settings.
It operates within a wide input voltage range of 12V – 24V and can produce up to 20kHz frequency output, making it suitable for demanding environments.
Its robust design allows operation from -40°C to +85°C, ensuring reliability under extreme conditions.
Equipped with overvoltage, overcurrent, and short-circuit protection features, this PWM board ensures safe and stable operation.
Additionally, it complies with CE, UL, and RoHS standards, making it a dependable choice for manufacturing, power electronics, and motor drive systems.
